Efficient VÖLKEL machine tap to ISO 529 standard, perfect for professional metalworking.
Technical drawing of a VÖLKEL thread tap with labeled diameters and lengths.
Efficient VÖLKEL machine tap to ISO 529 standard, perfect for professional metalworking.
Technical drawing of a VÖLKEL thread tap with labeled diameters and lengths.
M (ISO 529)

Machine Tap ISO 529 Form B HSS-G left hand thread - M 10 x 1.5 LH

Item no. 80820

€19.00

2 weeks delivery time
Application

Application:

for general use

  • non abrasive material up to 900 N/mm²
  • unalloyed and low alloyed steel
  • for through holes
Additional information
Type of thread metric ISO-thread
Standard ISO 529
Form Form B
Material HSS-G
Tolerance ISO2 (6H)
Size M 10 x 1.5 LH
Overall length (L1) 80 mm
Thread length (L2) 24 mm
Core hole diameter (D1) 8.5 mm
Shank diameter (D2) 10.0 mm
Drive connector 8.0 mm
EAN 4022835808206
Item number 80820
Type of flute straight fluted
Application for through holes
Thread standard DIN 13

Application:

for general use

  • non abrasive material up to 900 N/mm²
  • unalloyed and low alloyed steel
  • for through holes
Die visible through a larger die.
